Central Battery Units

In a centrally supplied system, the emergency and exit lights share a common power supply from a central battery unit. In normal conditions, the central battery unit monitors the mains voltage, maintains the charging of the batteries and supplies power to maintained luminaires. When mains supply is lost, the central battery unit supplies battery power to all the luminaires connected to it. Learn more about CBS technology

Addressable

Active filters

28-36 / 69 results
Product IP Class Nominal Supply Voltage Number of Output Circuits Output Voltage, Battery Supply (VDC) Nominal Output Voltage, Mains Supply (VAC) Tapsa Control Description
  • Tapsa Control Central Battery Unit TKT6740C
    Series 6

    TKT6740C

    Series 6
    E-number (FI) 7118964
    IP Class: IP31
    Nominal Supply Voltage: 3~ N/PE 220-240/380-415 VAC, 50/60 Hz
    Number of Output Circuits:
    Output Voltage, Battery Supply (VDC): 216
    Nominal Output Voltage, Mains Supply (VAC): 220-240 VAC
    Tapsa Control: Yes
    Description: Addressable central battery units for larger buildings
  • Tapsa Control Central Battery Unit TKT6732C
    Series 6

    TKT6732C

    Series 6
    E-number (FI) 7118963
    IP Class: IP31
    Nominal Supply Voltage: 3~ N/PE 220-240/380-415 VAC, 50/60 Hz
    Number of Output Circuits:
    Output Voltage, Battery Supply (VDC): 216
    Nominal Output Voltage, Mains Supply (VAC): 220-240 VAC
    Tapsa Control: Yes
    Description: Addressable central battery units for larger buildings
  • Tapsa Control Central Battery Unit TKT6724C
    Series 6

    TKT6724C

    Series 6
    E-number (FI) 7118961
    IP Class: IP31
    Nominal Supply Voltage: 3~ N/PE 220-240/380-415 VAC, 50/60 Hz
    Number of Output Circuits:
    Output Voltage, Battery Supply (VDC): 216
    Nominal Output Voltage, Mains Supply (VAC): 220-240 VAC
    Tapsa Control: Yes
    Description: Addressable central battery units for larger buildings
  • Tapsa Control Central Battery Unit TKT6716C
    Series 6

    TKT6716C

    Series 6
    E-number (FI) 7118960
    IP Class: IP31
    Nominal Supply Voltage: 3~ N/PE 220-240/380-415 VAC, 50/60 Hz
    Number of Output Circuits:
    Output Voltage, Battery Supply (VDC): 216
    Nominal Output Voltage, Mains Supply (VAC): 220-240 VAC
    Tapsa Control: Yes
    Description: Addressable central battery units for larger buildings
  • Tapsa Control Central Battery Unit TKT6624CP
    Series 6

    TKT6624CP

    Series 6
    E-number (FI) 7123922
    IP Class: IP34
    Nominal Supply Voltage: 1~ N/PE 220-240 VAC, 50/60 Hz
    Number of Output Circuits:
    Output Voltage, Battery Supply (VDC): 216
    Nominal Output Voltage, Mains Supply (VAC): 220-240 VAC
    Tapsa Control: Yes
    Description: Addressable central battery units for medium-sized and large buildings
  • Tapsa Control Central Battery Unit TKT6624CFP
    Series 6

    TKT6624CFP

    Series 6
    IP Class: IP34
    Nominal Supply Voltage: 3~ N/PE 220-240/380-415 VAC, 50/60 Hz
    Number of Output Circuits:
    Output Voltage, Battery Supply (VDC): 216
    Nominal Output Voltage, Mains Supply (VAC): 220-240 VAC
    Tapsa Control: Yes
    Description: Addressable central battery units for medium-sized and large buildings
  • Tapsa Control Central Battery Unit TKT6624CF
    Series 6

    TKT6624CF

    Series 6
    IP Class: IP20
    Nominal Supply Voltage: 3~ N/PE 220-240/380-415 VAC, 50/60 Hz
    Number of Output Circuits:
    Output Voltage, Battery Supply (VDC): 216
    Nominal Output Voltage, Mains Supply (VAC): 220-240 VAC
    Tapsa Control: Yes
    Description: Addressable central battery units for medium-sized and large buildings
  • Tapsa Control Central Battery Unit TKT6624C
    Series 6

    TKT6624C

    Series 6
    E-number (FI) 7118927
    IP Class: IP20
    Nominal Supply Voltage: 1~ N/PE 220-240 VAC, 50/60 Hz
    Number of Output Circuits:
    Output Voltage, Battery Supply (VDC): 216
    Nominal Output Voltage, Mains Supply (VAC): 220-240 VAC
    Tapsa Control: Yes
    Description: Addressable central battery units for medium-sized and large buildings
  • Tapsa Control Central Battery Unit TKT6616CP
    Series 6

    TKT6616CP

    Series 6
    E-number (FI) 7123921
    IP Class: IP34
    Nominal Supply Voltage: 1~ N/PE 220-240 VAC, 50/60 Hz
    Number of Output Circuits:
    Output Voltage, Battery Supply (VDC): 216
    Nominal Output Voltage, Mains Supply (VAC): 220-240 VAC
    Tapsa Control: Yes
    Description: Addressable central battery units for medium-sized and large buildings
